Tractor Hydraulic Remote 6 Port Diverter Valve Manual, 2 into 4 ports, Multiplier

Title: Manual Hydraulic Diverter Valve - 6-Port Remote Control Valve for Tractor - 2 Inlets to 4 Outlets Hydraulic Multiplier - Includes Mounting Bracket and Bolts. Product Overview: Expand your tractor's hydraulic functionality with this manual 6-port diverter valve.

This system converts a single remote into two double-acting circuits, allowing you to operate multiple hydraulic functions on trailers or rear-mounted implements using only one tractor remote. How It Works: If your tractor has only one set of hydraulic remotes but your attachment requires several functions, this diverter valve provides the perfect solution. Connect the diverter to your existing hydraulic remote. Position 1: Turn the lever to direct oil flow to the first function. Position 2: Turn the lever to direct oil flow to the second function. Only one function operates at a time, depending on lever position. Total of 3 pairs of ports - 1 pair connects to the tractor's remote outlet - 2 pairs connect to separate hydraulic circuits. Equipped with ISO 5675 (Poppet Type) quick couplers - compatible with ISO 7241-1 A standard. Suitable for most agricultural hydraulic systems.

Flow Rate: 15.85 Gpm. Hose Length: 70 cm (27.55").

Coupler Type: ISO 5675 (Poppet Style), Male & Female ½" BSP. Mounting: Bracket and bolts included.

Ideal For: Tractors, hydraulic trailers, and implements requiring multiple functions from a single hydraulic remote.

---
